Original Sinpro 3.5Vdc 25.7A 90W AC Adapter SPU130-101 8Pin Din 13.3 mm Switching 100 ~ 240VAC 47-6

Original Sinpro 3.5Vdc 25.7A 90W AC Adapter SPU130-101 8Pin Din 13.3 mm Switching 100 ~ 240VAC 47-63GHz 3.2A ITE RoHS Made in Taiwan Actually New may looks New Power Supply

Maker: Sinpro /ASTRODYNE Corporation
Input Voltage 90 VAC ~ 264 VAC 3.2A
Inrush Current 15A at 115 VAC / 30A at 230 VAC
Output: DC
Pin 1 = - Sense (-ve )
Pin 2,4,6 = Return
Pin 3 = Sense ( ve )
Pin 5,7,8 = 3.5V === 25.7A
Shell = (GND)
Tip type and Size: 8pin 13mm Din

Packing list:
1 x AC Adapter Power Adapter
1 X US UK EU AU ....Power Cable （fit your country）


Efficiency 80% Typ.
Hold Up Time 75 ms min.
Ripple & Noise 1%p-p max.
Operating Temperature 0XC to 70XC
Storage Temperature -40XC to 85XC
Protections OCP, OVP
UL/CUL, ITS-GS, CE, CB, CCC, IRAM, PSE, RoHS

Weight: 980grams
Dimension: 19.4x8.5x5 cm approx.
TO USE WITH:Medical equipment

Condition:
100% Original !
30-Days Money Back! 18 months Warranty!
Free Power Cord Fit your country!Fast Shipping!
Bid With Confidence!Nobody Beats Our Customer Services!
